PR002 - Speed Sensor Interface

The speed sensor interface allows you to use a gearbox or differential mounted factory electronic vehicle speed sensor (VSS) to operate a Monit measuring instrument. It will work with most types of sensors that produce either an analogue or digital pulse output. The interface contains special noise filtering circuitry to prevent interference and eliminate ground loop problems.

Monit PR002 speedo interface sensor

Technical Specifications

Hysteresis Voltage	2V
Max. Input Frequency	400Hz
Input Impedance	100Kohm
Operating Temperature	-20 to 125 deg C

Support Documents

(EN) PR002 Installation Guide.pdf (56kB)

(FR) PR002 Installation Guide.pdf (59kB)
